index I. Introduction

Human cytomegalovirus (CMV) can cause severe, life-threatening disease in immunocompromised patients such as transplant patients and patients with AIDS. Systemic infections are characterized by carriage of CMV in the polymorphonuclear leukocytes (PMNL) of peripheral blood (viremia). Infected PMNL can be detected by direct detection of CMV pp 65 antigen (CMV antigenemia) using an indirect immunofluorescence (IFA) technique. CMV antigenemia can also be used to monitor the course of CMV infection during and after treatment. Antigenemia will be performed on EDTA or heparinized blood requesting CMV. Antigenemia and culture will be performed on bone marrow samples requesting CMV.


II. Collection and Transport

A minimum of 5 mL of blood is collected in an EDTA Vacutainer® tube (purple top). Samples should be transported to the laboratory as soon as possible at room temperature. Smaller volumes of blood from infants will be accepted and the procedure will be completed despite a small number of PMNL’s. Blood samples received 14:00–13:00 hrs will be processed as far as preparation and fixing of slides. Staining and reading will be done the next day. Samples received after 15:00 hrs will be refrigerated and processed the next working day or a fresh sample requested (except on Fridays, consult Charge technologist).


Toronto Hospital Division of UHN: Reject (Transplant patients, In or Out patients)

1. Specimens received >24 hours after being taken.

2. Specimens received over the weekend (Friday after 2 p.m. to Sunday midnight)

Other sites (PMH, MSH): Only reject specimens if received over the weekend (i.e. >24 hours after collection.)

III. Materials:

a) Phosphate Buffered Saline:

For 1000 mL - 10 mM PBS powder, pH 7.4 (Sigma p-3813) in a glass vial

- 1000 mL dH20

Autoclave and store at room temperature.


Obtain sterile PBS from Rm. 977, ext. 8257.

ii) Erythrocyte Lysing Solution:

For 2000 mL -16.6 gm NH4CL power, M.W.53.49 (Sigma A-0171)

-2.0 gm Potassium bicarbonate

-2000 mL dH20

Filter sterilize and store at 4oC. Stable for 2 months.

iii) Fixative Solution:

For 500 mL -25 mL Formaldehyde (Sigma Cat. F-1268) (aliquot inside fume hood.)

-10 gm Sucrose, M.W. 342.3 (Sigma S-1888)

-500 mL PBS buffer

Store at room temperature. Stable for 1 month.

Use fresh aliquot of fixative each day.

iv) Wash Solution

For 500 mL -5.0 mL FCS

-500 mL PBS

Store at 4oC. Stable for 1 week.

v) Permeabilization Solution

For 500 mL -2.5 mL NP40 (ICN cat# 198596 formerly Nonidet, sigma)

-50 gm Sucrose (Sigma S-1888)

-5.0 mL Fetal Calf Serum (FCS)

-500 mL PBS

Store at 4oC. Stable for 1 month.

vi) Antibody 1

Monoclonal Anti-HCMV pp65, (Biotest Clonab CMV, Cat No: P/N 912600). Mix 1 mL of pp65 with 4 mL of PBS. Aliquot and store at 4oC. Test with a CMV positive control slide. Enter lot no. and QC slide results in Reagent History Form.

vii) Antibody 2

Monoclonal Anti-Mouse – FITC Conjugate with Evans Blue (Baxter B1029-86B). Store at 4oC.

viii) Control slides

In-house positive CMV control (stored at -20oC and prepared from positive patients cells).Use with first batch of slides being stained each day.

In-house positive CMV control (stored at 4oC and prepared from positive CMV cultures).These are double-well slide with CMV positive and negative wells.Use 1 control with each subsequent batch being stained.

Commercially prepared CMV control (stored at 4oC) Use with each new batch of PP65 that is prepared(or if there are no other control slides available)

IV. CMV Antigenemia Procedures:

A. Cell Separation Procedure

  1. Invert blood tube several times to mix.
  2. Transfer ~ 2 - 3 mL of blood to a 15 mL graduated centrifuge tube which contains 10 mL of ELS.
  3. Mix and put on a rotator for 5 minutes (or until RBC’s are lysed).
  4. Spin at 1300 rpm for 7 minutes.
  5. Gently pour supernatant into a discard container.
  1. Add 2 - 3 mL of ELS to tube to carefully rinse button. Do this 3 times.
  2. Add ELS to 10 mL level. Using a pipette, mix button with supernatant.
  3. Mix and spin at 1300 rpm for 7 minutes.
  4. Gently pour supernatant into a discard container.
  5. Add PBS solution to 10 mL level. Using a pipette, mix button with supernatant.
  6. Mix and spin at 1300 rpm for 7 minutes.
  7. Gently pour supernatant into a discard container. Carefully remove excess red blood cells from suspension above the WBC deposit.(fluff the cells by using the pipette to gently blow the RBC’s off the button).
  8. Gradually add PBS to cell pellet until it reaches a turbidity of ~ 1.0 to 2.0 MacFarland Standard.
  9. Proceed to cell counting procedure

  1. Cell Counting Procedure
  1. Before using Coulter Counter:

· Replace the blue Cleaner Solution with Isotonic Diluent in an ACCUVETTE II vial.

· Run the Isotonic Diluent 3 times using the Start/Stop key. (Record with check marks on the daily scheduled maintenance section on Equipment sheet Policy QEQMI103001hCoulter.01) in the black binder titled “Coulter Analyser History Log”. (Record with check marks on the daily scheduled maintenance section on Equipment sheet Policy QEQMI103001hCoulter.01) in the black binder titled “Coulter Analyser History Log”.

· On Mondays (or Tuesdays following a long weekend) run the CBC commercial control for Coulter Particle Counter (STRECK Para 4) as follows:

a. Remove vials from the refrigerator and allow to warm up to room temperature. (18-30C.)

b. Date the vial when it is used for the first time.

c. Use the red topped vial. (It is the lower control.)

d. Mix the vial by holding it horizontally between the palms of the hands. (Do NOT use a mechanical mixer). Roll the vial back and forth for 20-30 seconds; occasionally invert the vial. Mix well (to resuspend the red cells, but don not shake.

e. Gently invert the vial 8-10 times immediately before sampling.

f. Pipette 50ul of sample from the red topped vial into 10 mL of Isoton diluent.

g. Add 3 drops of Zap-oglobin and mix well.

h. Using the Coulter Particle Counter, count this sample 3 times. Record the counts in the Coulter Particle Counter Log Sheet found in the “Coulter Analyser History Log” black binder. Note: there is a separate log sheet for each kits lot number. Start a new sheet for each subsequent lot number. Also put a check mark in the appropriate box of the weekly scheduled maintenance sheet Policy QEQMI03001hCoulter.01. (also found in the black binder.) Put the manufacturers parameter sheet for each new lot number in the binder and put the date first used on the sheet.

  1. Dispense 10 mL of Isotonic Solution into an ACCUVETTE II vial for each sample.
  1. Invert cell suspension; dispense 50 uL of cell suspension into each ACCUVETTE II vial. Pipette up and down several times.
  1. Add 3 drops of ZAP-OGLOBIN (which will lyse any remaining RBC’s).
  2. Stir with transfer pipette to mix. Avoid introducing air bubbles.
  3. Read immediately two times and calculate the average WBC count (e.g. Reading of 2,200 E6 means the cell suspension has a WBC count of 2.2 x 106 /mL). Write down the average WBC count on the centrifuge tube.

Acceptable limit is between 1.0 x 106 to 2.0 x 106/mL

  1. Increase the volume added to the cytospin funnel if a specimen has a very low WBC count (maximum 300 uL). Each slide should have 200, 000 WBC’s.

NOTE: If you get a count just under 1.0 x 106, you could write x2 on the lid of the conical tube and double the amount added to the cytospin funnel.) If you do this, you must also double the count i.e. an initial count of 0.9 x 106/ml would be calculated as 1.8 x 106 /mL.

  1. At the end of the day:

· Immerse the Aperature Tube of the Coulter Counter into an ACCUVETTE II vial full of blue Cleaner Solution.

· Run the Cleaner Solution 3 times using the Start/Stop key.

· Leave the Aperature Tube immersed in the Cleaner Solution overnight. . (Record with check marks on the daily scheduled maintenance section on Equipment sheet Policy QEQMI103001hCoulter.01) in the black binder titled “Coulter Analyser History Log”.

  1. Preparation of Slides

1. Dispense 200 ul of cell suspension from ACCUVETTE II vial (see above) into a

single cytospin funnel.

2. Spin at 900 rpm for 3 minutes in a SHANDON Cytocentrifuge.

3. Air dry slide for 5 minutes inside the Laminar Flow Hood.

D. Fixation and Permeabilization of Slides

  1. Immerse prepared slides in Fixative Solution for 10 minutes.

2. Rinse in Wash Solution for 5 minutes.

3. Immerse in Permeabilization Solution for 5 minutes.

4. Rinse in Wash Solution for 5 minutes.

5. Let slides dry in Laminar Flow Hood for 5 minutes and proceed to staining, or store dried slides in fridge at 4oC for up to 72 hr. Store in -70oC freezer if slides cannot be stained within 72 hr.

E. Staining of Slides

1. Place one double-well control slide with CMV positive and negative cell spots at a random position within each batch of slides to be stained.

  1. Add 20 ml of working solution monoclonal antibody # 1 (anti-pp65) onto the sample and control slide. Incubate in a humidified chamber at 37°C for 30 minutes. FROM THIS POINT, DO NOT ALLOW THE CYTOPREP TO DRY AT ANY TIME DURING THE STAINING PROCESS.
  1. Wash by immersion in fresh PBS 3 times for 1 minute each.
  1. Wipe excess PBS off slide and add 20 ml of fluorescein conjugated antibody # 2 to the cytoprep. DO THIS ONE SLIDE AT A TIME, DO NOT ALLOW CELL SPOT TO DRY IN BETWEEN.
  1. Incubate for 30 minutes at 37°C in a humidified chamber.
  1. Wash by immersion in fresh PBS 3 times for 2 minutes each. Wash in fresh dH2O briefly.
  1. Allow slides to dry under hood about 5 minutes.
  1. Coverslip slides with FA mounting media.
  1. Reading of Slides

a. Reading is performed with the fluorescence microscope using the #4 filter (λ 490/575). Scan the entire surface of the cytoprep with the 40x objective, counting the number of infected cells.

The fluorescent, green polylobate nuclei are the infected and stained PMNL's.

A single fluorescent PMNL is sufficient to indicate a positive antigenemia result.

The following appearances DO NOT constitute a positive:

- cytoplasmic fluorescence in large granules (eosinphils)

- slightly greenish periphery of PMNL

- all of the PMNLs appear greenish

- peri-nuclear staining of PMNLs

b. Calculation of positive CMV antigenemia cell count performed in LIS:

Under DPP 65, at the media screen:

WBC#: WBC count from Coulter Counter, written on each centrifuge tube after counting.

PREP: # of positive cells seen in cytospin slide

DIV2: # of positive cells divided by 2


F7, put 'V' in isolate # field, Enter, Enter, F2 under 'Org id', F12, choose 1 for CMV, F8, V,and '8' , F12, F12.

  1. Daily Quality Control:

a. Check reagent expiratory date and verify that Reagent QC is satisfactory for the reagent lot/kit being used

b. Appropriate control slide with positive and negative CMV wells (commercial; home-made slide with ATCC strain or buffer coat of known CMV positive are acceptable) must be stained with each batch. Place QC slide at a random position within each batch

c. Examine the negative control well first to establish the dull red colour (Evans blue counterstain) and to determine if there is any nonspecific staining.

The positive control must be clearly distinguishable from the negative control or the test is invalid.

d. Record daily QC results in LIS (under procedure VPP65D, CMV pp65 - daily QC

STN Staining Reaction).

Failed Daily QC:

a. Do not release patient results pending resolution of QC error.

b. Inform charge/senior technologist.

c. Record in Reagent Log, Instrument Log if microscope/incubator is involved in the failure and file incident report as appropriate.

d. Re-run failed controls in parallel to fresh controls (and/or external QC) to evaluate the QC material itself.

e. If the re-run shows the old QC material still fails, fresh QC passes and nothing else is wrong with the batch (only the old QC material failed, patient results valid) patient results may be released.

Marked decrease/absence in fluorescence can be due to:

a. Reagent deterioration/skipping (did not apply primary/secondary stain)

b. Microscope (filter, bulb, alignment)

c. Other equipment, reagents or technique

IV. Reporting Results

CMV Antigenemia: Negative Report: “Negative for Cytomegalovirus.”

Positive Report*: “POSITIVE, - # positive cells/100,000 (Status result as “Interim”)

V. References

1. Clonatec Co.: Detection of HCMV 65 Kda protein kinase in peripheral blood polymorphonuclear leukocytes by indirect immunofluorescence. Clonatec, Biosoft Department Siege social: 60 rue de Wattignies, 75580, Paris Cedex 12 Tel. (1) 43 42 38 30, Fax (1) 43 40 48 86.

2. Gerna, G. et al. Comparison of different immunostaining techniques and monoclonal antibodies to the lower matrix phosphoprotein (pp65) for optimal quantitative of human cytomegalovirus antigenemia. J. Clin. Micr. 1992; 30: 1232 – 1237.

3. Niubo J. et al. Association of quantitative cytomegalovirus antigenemia with symptomatic infection in solid organ transplant patients. Diagn. Microbiol. Infect. Dis. 1996; 24: 19-24.

4. Ho S. et al. Rapid cytomegalovirus pp65 antigenemia assay by direct lysis and immunofluoresence staining. J. Clin. Micro. 1998; 36;638-640.
